Seamless Stainless Steel Pipe

Seamless stainless steel pipe is a long strip of steel with a hollow section and no seams around it. The thicker the wall thickness of the product, the more economical and practical it is, and the thinner the wall thickness, the higher its processing cost will be.
The process of this product determines its limited performance. Generally, seamless steel pipes have low precision: uneven wall thickness, low brightness inside and outside the tube, high cost of cutting to length, and pits and black spots on the inside and outside are not easy to remove; its detection and Shaping must be handled offline. Therefore, it embodies its superiority in terms of high pressure, high strength, and mechanical structural materials.

Manufacturing method:
According to different production methods, it can be divided into hot-rolled tubes, cold-rolled tubes, cold-drawn tubes, extruded tubes, etc.
1. Hot-rolled seamless stainless steel pipe are generally produced on automatic pipe rolling units. After checking and removing surface defects, the solid tube blank is cut into the required length, centered on the perforated end face of the tube blank, then sent to the heating furnace for heating, and pierced on the piercing machine. Spin and advance the solid blank inside the process of piercing holes under the influence with the roller as well as the end. Then the solid blank is hollow finally, which is called gross pipe. Send to the automatic pipe rolling machine to continue rolling. Finally, the wall thickness is adjusted by the equalizing machine, and the size is sized by the sizing machine to meet the specification requirements. It is a more advanced method to produce hot-rolled seamless steel pipes by using continuous rolling mills.
2. If you want to obtain seamless pipes with smaller size and better quality, you must use cold rolling, cold drawing or a combination of the two. Cold rolling is usually carried out on a two-roll mill, and the steel pipe is rolled in an annular pass formed by a circular hole groove with variable cross-section and a stationary tapered plug. Cold drawing is usually carried out on a 0.5-100T single-chain or double-chain cold drawing machine.
3. The extrusion method is to place the heated tube blank in a closed extrusion cylinder, and the perforated rod and the extrusion rod move together to make the extruded part extrude from the smaller die hole. This method can produce steel pipes with smaller diameters.
This type of steel pipe can be divided into two categories: seamless stainless steel pipe and stainless steel welded steel pipe (seamed pipe). According to different manufacturing processes, it can be divided into several basic types: hot rolling, extrusion, cold drawing and cold rolling. The cross-sectional shape can be divided into round tubes and special-shaped tubes. Round steel tubes are widely used, but there are also some special-shaped stainless steel tubes such as square, rectangular, semicircular, hexagonal, equilateral triangle, and octagonal.
For steel pipes under fluid pressure, a hydraulic test is required to check their pressure resistance and quality. It is qualified if no leakage, soaking or expansion occurs under the specified pressure. Some steel pipes also need to be crimped according to standards or requirements , Flaring test, flattening test.
Seamless stainless steel pipe, also known as stainless steel seamless pipes, are made of steel ingots or solid tube blanks that are perforated into capillary tubes, and then made by hot rolling, cold rolling or cold drawing. The specifications of seamless steel pipes are expressed in millimeters of outer diameter * wall thickness

The characteristics of seamless stainless steel pipe
Seamless stainless steel pipe is made of high-quality steel and has the following characteristics:
1. High temperature resistance and strong corrosion resistance.
2. Withstand high pressure, able to withstand high temperature, high pressure and large flow.
3. The inner surface is smooth, and the liquid fluid resistance is small.
4. High processing precision and precise size.
5. The seamless pipe has high strength and is not easy to break.

Application of seamless stainless steel pipe
1. Petroleum and chemical industries: seamless stainless steel pipe are widely used in petroleum, natural gas and other fields. Due to its high temperature resistance and good corrosion resistance, it is suitable for manufacturing high-pressure oil and gas pipelines, chemical pipelines, petroleum pipelines, etc.
2. Pharmaceutical industry: seamless stainless steel pipe have important applications in the field of pharmaceutical manufacturing. Pharmaceutical manufacturing requires the use of high-purity piping materials, and stainless steel seamless pipes have excellent chemical properties and no pollution, and are suitable for manufacturing pharmaceutical production equipment, infusion sets, and artificial crystals.
3. Food industry: seamless stainless steel pipe also have important applications in the field of food manufacturing. Due to its antibacterial properties, it is suitable for the manufacture of food storage tanks, dairy equipment, beverage equipment, etc.
4. Machinery manufacturing industry: seamless stainless steel pipe are also widely used in the machinery manufacturing industry. In addition to the above industries, stainless steel seamless pipes are also used in the manufacture of automobile exhaust pipes, industrial water pipes, aero engine pipes, etc.
5. Construction industry: seamless stainless steel pipe can also be used in construction equipment manufacturing, such as cranes, elevators and so on.

Seamless stainless steel pipe are widely used in modern industry. Its high strength, corrosion resistance, high temperature, high pressure and other characteristics make it widely used in petroleum, chemical, pharmaceutical, food, machinery manufacturing and other industries. With the continuous advancement of technology, the application fields of seamless stainless steel pipe will continue to expand.

The standard specification of seamless stainless steel pipe is an important factor to ensure the quality of seamless stainless steel pipe products. The following are common seamless stainless steel pipe standards

Chinese standard:
Seamless stainless steel pipe product standards mainly include GB/T14976, GB/T13296, GB/T12771 and so on. GB/T14976 is a standard specification for seamless stainless steel pipe implemented in my country, which is suitable for the production of seamless stainless steel pipe for various corrosion-resistant, high-temperature-resistant, and high-pressure equipment.

American standard:
The common ones are ASTM A312, ASTM A213, ASTM A269 and other standards. ASTM A312 is a common seamless stainless steel pipe standard for welded and seamless stainless steel tubing for general purposes. ASTM A213 is a standard specification for stainless steel and alloy seamless tubing for use in piping and heat exchange equipment at high temperatures and pressures.

Japanese standard:
JIS G3456-88 Stainless Steel Tubes for Machine Structures, JIS G3448-88 Stainless Steel Tubes for Ordinary Pipes, JIS G3459-88 Stainless Steel Tubes for Pipelines, JIS G3463-88 Stainless Steel Tubes for Boilers and Heat Exchangers

Seamless stainless steel pipe need to understand the corresponding standard specifications to ensure product quality and use safety. At the same time, it is necessary to pay attention to the scope of application of different standards and the quality requirements of raw materials.

The specifications and materials of seamless stainless steel pipe depend on specific application scenarios and requirements.
Generally speaking, common seamless stainless steel pipe specifications include outside diameters from 1/8 inch to 30 inches, wall thicknesses from 0.035 inches to 4 inches, and lengths from random to 40 feet.
Commonly used materials include austenitic stainless steel, duplex stainless steel, ferritic stainless steel, superalloy, etc., among which austenitic stainless steel is the most common material, with excellent corrosion resistance, toughness, weldability, etc., widely used in chemical industry , petroleum, medical equipment and other industries.
