Duplex Stainless Steel Coil

Duplex stainless steel coil & sheet belong to a class of steels known as duplex steels. Duplex steel plates were created to benefit from the benefits of both ferritic and austenitic steels. The microstructure of dual phase steel contains almost equal proportions of ferrite and austenite metal phases. Duplex steels contain no carbon and have 3% to 9% molybdenum additions. It also contains 21% to 30% chromium. The addition and amount of these materials give stainless steel duplex plates extraordinary corrosion resistance and tensile strength.

Benefits of Duplex stainless steel coil & sheet:
Excellent corrosion resistance: Duplex stainless steel coil & sheet has excellent corrosion resistance to a wide range of corrosive media, including acidic, alkaline and chloride environments.
High Strength: Duplex stainless steel coil & sheet has high strength, giving it excellent load-bearing capability in structural applications. Compared to traditional austenitic stainless steels, duplex stainless steel coil & sheet are stronger, helping to reduce material usage and component size.
Excellent toughness: Duplex stainless steel coil & sheet combines the properties of ferrite and austenite, giving it good toughness.
Good weldability: Duplex stainless steel coil & sheet has good weldability and can be joined by conventional welding methods.
Good resistance to stress corrosion cracking: Duplex stainless steel coil & sheet has excellent resistance to stress corrosion cracking, making it suitable for applications in highly stressful environments such as chemical equipment and marine engineering.

Applications ofDuplex stainless steel coil & sheet
Excellent corrosion resistance with increased strength and affordable pricing makes duplex stainless steel a popular choice for a variety of industries. Their wide uses are found in:
1.Chemical and liquid processing
2.Offshore (flowlines, risers) and other industrial operations
3.Naval parts and components
4.Pulp and paper production
5.Pollution control equipment
6.Water Treatment/Desalination plants
7.Construction, Infrastructure, Architecture
8.Hot water and brewing tanks
9.Food and Drink Storage
10.Boilers, Heat exchangers, pressure vessels
11.Marine Tanks
12.Renewable Energy
13.Nuclear Industry
Duplex stainless steel coil & sheet are extremely corrosion resistant, work hardenable alloys.  Their microstructures consist of a mixture of austenite and ferrite phases.  As a result, duplex stainless steels display properties characteristic of both austenitic and ferritic stainless steels.

Duplex stainless steel coil & sheet vary from country to country. The following are some common Chinese, British, American and Japanese national standards:

Chinese standard:
GB/T 20878-2007 "Stainless steel and heat-resistant steel grades and chemical composition"

British Standard:
BS EN 10088-2-2014 "Stainless steel. Technical delivery conditions for general purpose corrosion resistant steel sheet/plate and strip"

American standard:
ASTM A240/A240M-20a, Standard Specification for Pressure Vessels and Chromium and Chromium-Nickel Stainless Steel Plate, Sheet, and Strip

Japanese standard:
JIS G4304:2005 "Hot-rolled stainless steel plate, sheet and strip"

This standard specifies the grades and chemical compositions of stainless steel and heat-resistant steel, and includes the physical parameters of some grades, the comparison table of foreign standard grades, applicable standards for stainless steel and heat-resistant steel grades, etc. in the form of informative appendices.

Duplex stainless steel coil & sheet is a high-strength, high-corrosion-resistant pipe that is widely used in petroleum, chemical, pharmaceutical, food and other industries. Its specifications include parameters such as outer diameter, wall thickness, and length:

The outer diameter of duplex stainless steel thick-walled pipe: between 6mm and 630mm
Wall thickness is generally between 0.5mm-40mm
The length is generally between 3m-12m

Permissible deviation of outer diameter: ±0.13~±0.76
Allowable deviation of wall thickness: ±10%~±15%
